Description

Product details

Takeoff weight 835g Dimensions (including blades) Folded: 210×123×95mm Unfolded: 427×384×95mm Wheelbase 368mm Max ascent speed 5m/s (sport), 4m/s (standard), 3m/s (smooth) Max descent speed 4m/s (sport), 3m/s (standard), 2m/s (smooth) Max level flight speed(no wind, near sea level) 18m/s (sport), 10m/s (standard), 5m/s (smooth) Max takeoff altitude 4000m Max flight time (no wind) 40min Max hovering time (no wind) 38min Max flight distance (no wind) 24km Max wind resistance Level 7 Max tilt angle 33°(sport), 25°(standard), 25°(smooth) Max angular velocity 200°(sport), 120°(standard), 60°(smooth) Operating temperature 0°C ~ 40°C Operating frequency 2.400-2.4835GHz，5.725-5.850GHz,5.150-5.250GHz Transmission power (EIRP) FCC:≤30dBm；CE:≤20dBm GNSS GPS, GLONASS, Galileo Hovering accuracy Vertical:±0.1m (when the visual positioning is active), ±0.5m (with GPS positioning); Horizontal:±0.3m (when the visual positioning is active), ±1.5m (with GPS positioning);
