Description

Aircraft Weight (Battery & Propellers Included) 1375 g Diagonal Size (Propellers Excluded) 350 mm Max Ascent Speed S-mode: 6 m/s P-mode: 5 m/s Max Descent Speed S-mode: 4 m/s P-mode: 3 m/s Max Speed S-mode: 45 mph (72 kph) A-mode: 36 mph (58 kph) P-mode: 31 mph (50 kph) Max Pitch Angle S-mode: 42° A-mode: 35° P-mode: 25° Max Angular Speed S-mode: 250°/s A-mode: 150°/s Max Service Ceiling Above Sea Level 19685 ft (6000 m) Max Wind Speed Resistance 10 m/s Max Flight Time Approx. 30 minutes Operating Temperature Range 32° to 104°F (0° to 40°C) Satellite Positioning Systems GPS/GLONASS Hover Accuracy Range Vertical: ±0.1 m (with Vision Positioning) ±0.5 m (with GPS Positioning) Horizontal: ±0.3 m (with Vision Positioning) ±1.5 m (with GPS Positioning) Gimbal Stabilization 3-axis (pitch, roll, yaw) Controllable Range Pitch: -90° to +30° Max Controllable Angular Speed Pitch: 90°/s Angular Vibration Range ±0.02° Vision System Vision System Forward Vision System Backward Vision System Downward Vision System Velocity Range ≤31 mph (50 kph) at 6.6 ft (2 m) above ground Altitude Range 0-33 ft (0-10 m) Operating Range 0-33 ft (0-10 m) Obstacle Sensory Range 2-98 ft (0.7-30 m) FOV Forward: 60° (Horizontal), ±27° (Vertical) Backward: 60° (Horizontal), ±27° (Vertical) Downward: 70° (Front and Rear), 50° (Left and Right) Measuring Frequency Forward: 10 Hz Backward: 10 Hz Downward: 20 Hz Operating Environment Surface with clear pattern and adequate lighting (lux>15) Infrared Sensing System Obstacle Sensory Range 0.6-23 feet (0.2-7 m) FOV 70° (Horizontal), ±10° (Vertical) Measuring Frequency 10 Hz Operating Environment Surface with diffuse reflection material, and reflectivity > 8% (such as wall, trees, humans, etc.) Camera Sensor 1-inch CMOS Effective pixels: 20M Lens FOV 84° 8.8 mm/24 mm (35 mm format equivalent) f/2.8-f/11 auto focus at 1 m-∞ ISO Range Video: 100-3200 (Auto) 100-6400 (Manual) Photo: 100-3200 (Auto) 100-12800 (Manual) Mechanical Shutter Speed 8-1/2000 s Electronic Shutter Speed 8-1/8000 s Image Size 3:2 Aspect Ratio: 5472×3648 4:3 Aspect Ratio: 4864×3648 16:9 Aspect Ratio: 5472×3078 PIV Image Size 4096×2160 (4096×2160 24/25/30/48/50p) 3840×2160 (3840×2160 24/25/30/48/50/60p) 2720×1530 (2720×1530 24/25/30/48/50/60p) 1920×1080 (1920×1080 24/25/30/48/50/60/120p) 1280×720 (1280×720 24/25/30/48/50/60/120p) Still Photography Modes Single Shot Burst Shooting: 3/5/7/10/14 frames Auto Exposure Bracketing (AEB): 3/5 bracketed frames at 0.7 EV Bias Interval: 2/3/5/7/10/15/20/30/60 s Video Recording Modes H.265 C4K: 4096×2160 24/25/30p @100Mbps 4K: 3840×2160 24/25/30p @100Mbps 2.7K:2720×1530 24/25/30p @65Mbps 2.7K: 2720×1530 48/50/60p @80Mbps FHD: 1920×1080 24/25/30p @50Mbps FHD: 1920×1080 48/50/60p @65Mbps FHD: 1920×1080 120p @100Mbps HD:1280×720 24/25/30p @25Mbps HD: 1280×720 48/50/60p @35Mbps HD: 1280×720 120p @60Mbps H.264 C4K: 4096×2160 24/25/30/48/50/60p @100Mbps 4K: 3840×2160 24/25/30/48/50/60p @100Mbps 2.7K: 2720×1530 24/25/30p @80Mbps 2.7K: 2720×1530 48/50/60p @100Mbps FHD: 1920×1080 24/25/30p @60Mbps FHD: 1920×1080 48/50/60 @80Mbps FHD: 1920×1080 120p @100Mbps HD: 1280×720 24/25/30p @30Mbps HD: 1280×720 48/50/60p @45Mbps HD: 1280×720 120p @80Mbps Max Video Bitrate 100 Mbps Supported File Systems FAT32 (≤32 GB); exFAT (>32 GB) Photo JPEG, DNG (RAW), JPEG + DNG Video MP4/MOV (AVC/H.264; HEVC/H.265) Supported SD Cards microSD Max Capacity: 128 GB Write speed ≥15MB/s, Class 10 or UHS-1 rating required Operating Temperature Range 32° to 104°F (0° to 40°C) Remote Controller Operating Frequency 2.400-2.483 GHz and 5.725-5.850 GHz Max Transmission Distance 2.400-2.483 GHz, 5.725-5.850 GHz (Unobstructed, free of interference) FCC: 10000 m CE: 6000 m SRRC: 6000 m MIC: 6000 m Operating Temperature Range 32° to 104°F (0° to 40°C) Battery 6000 mAh LiPo 2S Transmitter Power (EIRP) 2.400-2.483 GHz FCC: 26 dBm CE: 20 dBm SRRC: 20 dBm MIC: 17 dBm 5.725-5.850 GHz FCC: 26 dBm CE: 14 dBm SRRC: 20 dBm MIC: - Operating Current/Voltage 1.2 A@7.4 V Video Output Port GL300K: HDMI GL300L: USB Mobile Device Holder GL300K: Built-in display device (5.5-inch screen, 1920×1080, 1000 cd/m2, Android system, 4 GB RAM＋16 GB ROM) GL300L: Tablets and smart phones Charger Voltage 17.4 V Rated Power 100 W Intelligent Flight Battery Capacity 5870 mAh Voltage 15.2 V Battery Type LiPo 4S Energy 89.2 Wh Net Weight 468 g Charging Temperature Range 41° to 104°F (5° to 40°C) Max Charging Power 160 W App / Live View Mobile App DJI GO 4 Live View Working Frequency 2.4 GHz ISM, 5.8 GHz ISM Live View Quality 720P @ 30fps, 1080P @ 30fps Latency Phantom 4 Pro V2.0: 220 ms (depending on conditions and mobile device) Phantom 4 Pro+ V2.0: 160-180 ms
