Description

Weight (Battery & Propellers Included) 1380 g Diagonal Size (Propellers Excluded) 350 mm Max Ascent Speed S-mode: 6 m/s Max Descent Speed S-mode: 4 m/s Max Speed S-mode: 20 m/s Max Pitch Angle S-mode: 42° A-mode: 35° P-mode: 15° Max Angular Speed S-mode: 200°/s A-mode: 150°/s Max Service Ceiling Above Sea Level 19685 feet (6000 m) Max Wind Speed Resistance 10 m/s Max Flight Time Approx. 28 minutes Operating Temperature Range 32° to 104°F (0° to 40°C) Satellite Positioning Systems GPS/GLONASS Hover Accuracy Range Vertical: ±0.1 m (with Vision Positioning) ±0.5 m (with GPS Positioning) Horizontal: ±0.3 m (with Vision Positioning) ±1.5 m (with GPS Positioning) Gimbal Stabilization 3-axis (pitch, roll, yaw) Controllable Range Pitch: -90° to +30° Max Controllable Angular Speed Pitch: 90°/s Angular Vibration Range ±0.02° Vision System Vision System Forward Vision System Downward Vision System Velocity Range ≤10 m/s (2 m above ground) Altitude Range 0 - 33 feet (0 - 10 m) Operating Range 0 - 33 feet (0 - 10 m) Obstacle Sensory Range 2 - 49 feet (0.7 - 15 m) FOV Forward: 60°(Horizontal), ±27°(Vertical) Downward: 70°(Front and Rear), 50°(Left and Right) Measuring Frequency Forward: 10 Hz Downward: 20 Hz Operating Environment Surface with clear pattern and adequate lighting (lux>15) Camera Sensor 1/2.3” CMOS Effective pixels:12.4 M Lens FOV 94° 20 mm (35 mm format equivalent) f/2.8 focus at ∞ ISO Range 100-3200 (video) 100-1600 (photo) Electronic Shutter Speed 8 - 1/8000 s Image Size 4000×3000 Still Photography Modes Single shot Burst shooting: 3/5/7 frames Auto Exposure Bracketing (AEB): 3/5 bracketed frames at 0.7 EV Bias Timelapse HDR Video Recording Modes UHD: 4096×2160 (4K) 24 / 25p 3840×2160 (4K) 24 / 25 / 30p 2704×1520 (2.7K) 24 / 25 / 30p FHD: 1920×1080 24 / 25 / 30 / 48 / 50 / 60 / 120p HD: 1280×720 24 / 25 / 30 / 48 / 50 / 60p Max Video Bitrate 60 Mbps Supported File Systems FAT32 (≤32 GB); exFAT (>32 GB) Photo JPEG, DNG (RAW) Video MP4, MOV (MPEG-4 AVC/H.264) Supported SD Cards Micro SD Max capacity: 64 GB Class 10 or UHS-1 rating required Operating Temperature Range 32° to 104°F (0° to 40°C) Remote Controller Operating Frequency 2.400 - 2.483 GHz Max Transmission Distance FCC Compliant: 3.1 mi (5 km) CE Compliant: 2.2 mi (3.5 km) (Unobstructed, free of interference) Operating Temperature Range 32° to 104°F (0° to 40°C) Battery 6000 mAh LiPo 2S Transmitter Power (EIRP) FCC: 23 dBm CE: 17 dBm MIC: 17 dBm Operating Current/Voltage 1.2 A@7.4 V Video Output Port USB Mobile Device Holder Tablets and smart phones Charger Voltage 17.4 V Rated Power 100 W Intelligent Flight Battery Capacity 5350 mAh Voltage 15.2 V Battery Type LiPo 4S Energy 81.3 Wh Net Weight 462 g Charging Temperature Range 41° to 104°F (5° to 40°C) Max Charging Power 100 W App / Live View Mobile App DJI GO 4 Live View Working Frequency 2.4 GHz ISM Live View Quality 720P @ 30fps Latency 220ms (depending on conditions and mobile device)
